TM21R Series q Modular Jack Connectors for High-Speed LAN Transmission
q Double row / multiple port, with Built-in Optical Pipe
TM21R-5B-3232D-LP(50)
A
B
13.97 Contact No.8
Upper row
Contact No.1
32.5
(6)
0.45 Contact No.1
0.25
C
D
Contact No.8
Lower row
(3.5)
1.4
2.5
14.94
0.35
1
Lower row connectors
contacts
1
10.25
22.125
2 3 5 8
1 4 6 7
7 6 4 1
8 5 3 2
Upper row connectors contacts
TM21R-5B-4848D-LP(50)
11.9
7.7
Part Number
TM21R-5B-3232D-LP(50)
TM21R-5B-4848D-LP(50)
CL No.
222-2879-1-50
222-2885-4-50
A
59.18
87.12
B
41.91
69.85
C
53.81
81.75
D
58.93
86.87
RoHS
YES
B Recommended PCB mounting pattern
A
B
4
4
Upper row LED
mount position
Lower row LED
mount position
1.2
11.9
7.7
LED light
emission area
E- ?2
13.97
8.89
6.35
3.81
1.27
Upper row contact hole
Lower row contact hole
8 5 3 2
7 6 4 1
D- ?1
1 4 6 7
2 3 5 8
4- ?2
1
Contact No.
No conductive traces
2
Printed board edge
2- ?3.2
C
Connector front edge
Part Number
TM21R-5B-3232D-LP(50)
TM21R-5B-4848D-LP(50)
CL No.
222-2879-1-50
222-2885-4-50
A
58.93
86.87
B
41.91
69.85
C
53.81
81.75
D
64
96
E
4
6
* Recommendations for PCB Design
1 PCB mounting pattern
1 The contact arrangement differs between the contact area side and
Printed board side. (1,2,3,4,5,6,7,8 on the contact are side /
Other Series
TM21R Series
2,1,3,4,5,6,8,7 on the printed board side)
2 Areas indicated should be free of conductive traces.
3 Recommended board thickness: 1.6mm.
4 To assure that the indicator light pipes operates correctly the LED ' s
8
1
7
2
6
3
5
4
4
5
3
6
2
7
1
8
7
2
8
1
6
3
5
4
4
5
3
6
1
8
2
7
must be installed directly on the PCB, within recommended dimensions
and with light emitting center in upward direction.
4 Suggested LEDs
Contact applicable manufacturer for LED specification.
Series Name
CL-220
Manufacturer
Citizen Electronics Co., Ltd.
7
